In this blog, we will learn about why we scale the dot product attention by √dₖ in the Transformer architecture with a step-by-step numeric example.

If you have already read our blog on Math behind Attention - Q, K, and V, you know the attention formula and the computation steps. In that blog, we divided the attention scores by sqrt(d_k) and moved on. Now, it is time to understand why we do that. Why exactly sqrt(d_k)? Why not divide by 2 or 10 or any other number?

The goal is to make you understand why we scale by √dₖ, which means that there are a few simplifications done while writing this. If you understand the reasoning behind the scaling, then my mission will be accomplished. If you read this article completely, I am sure my mission will be accomplished.

We will cover the following:

The Attention Formula (Quick Recap)
What Happens Without Scaling?
Why Do Dot Products Grow with dₖ?
Understanding Variance of the Dot Product
Proving It Step by Step: Variance of the Dot Product is dₖ
What Large Dot Products Do to Softmax
Why √dₖ is the Right Scaling Factor
Seeing It with Real Numbers
Putting It All Together

Let's get started.

The Attention Formula (Quick Recap)

The formula for Scaled Dot-Product Attention is:

Attention(Q, K, V) = softmax(Q x K^T / sqrt(d_k)) x V

Here:

Q is the Query matrix
K is the Key matrix
V is the Value matrix
d_k is the dimension of the Key vector
sqrt(d_k) is the square root of d_k

The part we are focusing on today is / sqrt(d_k). This is the scaling factor. We divide the dot product scores by the square root of the Key dimension before passing them to softmax.

Now, the question is: why do we need this scaling? The answer lies in understanding what happens without it.

What Happens Without Scaling?

Let's say we skip the scaling step and compute attention directly as below:

Attention = softmax(Q x K^T) x V

In real Transformer models, d_k is 64, 128, or even larger. When d_k is large, the scores Q x K^T can become very large numbers (we will see why in the next section). And when we pass very large values into softmax, something bad happens.

The softmax function (which converts scores into probabilities) produces outputs that are extremely close to 0 and 1. One word gets almost all the attention (close to 1.0), and all other words get almost no attention (close to 0.0). The model stops spreading attention across multiple relevant words. It becomes too confident about one single word.

This is a big problem because:

The model cannot learn from multiple words at once.
The gradients (the signals used to update the model during training) become extremely small, almost zero. This is called the vanishing gradient problem.
When gradients are too small, the model stops learning effectively.

So, here comes the scaling by sqrt(d_k) to the rescue.

But before we understand the solution, we must first understand why dot products grow when d_k increases.

Why Do Dot Products Grow with dₖ?

The dot product of two vectors is computed by multiplying each pair of elements and then adding them all up.

Let's say we have two vectors q and k, each of dimension d_k:

dot_product = q_1*k_1 + q_2*k_2 + q_3*k_3 + ... + q_{d_k}*k_{d_k}

Here, we are adding d_k number of terms together.

Now, let's think about this simply. Each term q_i * k_i is a number. It can be positive or negative. When we add more and more of these numbers together, they do not always cancel out perfectly. Some add up, some cancel, but overall the total tends to grow in magnitude. The more dimensions we have, the more terms we add, and the larger the dot product can become.

For example, if d_k = 4, we are adding just 4 terms, so the dot product stays small. But if d_k = 512, we are adding 512 terms. Even though some positive and negative values cancel out, the sheer number of terms makes the total much larger in magnitude.

The dot product grows with d_k. This is the core problem. The larger the dimension, the larger the dot product, and the worse the softmax behaves.

Now, let's understand this more precisely using the concept of variance.

Understanding Variance of the Dot Product

Do not worry, we will keep this simple.

Variance tells us how spread out a set of values can be from the average. A high variance means the values are far from the average. A low variance means the values stay close to the average.

Suppose we are measuring the height of students in a class. If all students are between 5.0 and 5.5 feet, the variance is low. If students range from 3.0 to 7.0 feet, the variance is high. Similarly, when we talk about the variance of the dot product, we are asking: how spread out can the dot product values be?

Now, let's assume that each element in the Query vector and the Key vector is a random number with:

Mean (average) = 0
Variance = 1

This is a standard assumption in machine learning. The input values are typically normalized to have zero mean and unit variance.

Now, what is the variance of one single product q_i * k_i?

When we multiply two independent random numbers, each with mean 0 and variance 1, the result has:

Mean = 0
Variance = 1 x 1 = 1 (we will see why in the next section)

So, each individual product q_i * k_i has a variance of 1.

Now, the dot product is the sum of d_k such products:

dot_product = q_1*k_1 + q_2*k_2 + ... + q_{d_k}*k_{d_k}

When we add d_k independent terms, each with variance 1, the total variance is:

Variance(dot_product) = d_k x 1 = d_k

This is the key insight. The variance of the dot product is equal to dₖ. The larger the d_k, the more spread out the dot product values become. And more spread out values cause problems for softmax.

Proving It Step by Step: Variance of the Dot Product is dₖ

Now, let's prove why the variance equals d_k, step by step, for the sake of understanding. Do not worry, we will keep it simple.

We already know that the mean of our dot product is zero (because the average value of each q_i and k_i is zero).

Now, in general, variance is calculated as below:

Variance = Average of (value - mean)^2

But since our mean is zero, this becomes:

Variance = Average of (value - 0)^2
         = Average of value^2

So, when the mean is zero, the variance simplifies to the average of the squared values. This means we need to find the average of the squared dot product.

Now, let's see what happens when we square the dot product. Let's take a small example with d_k = 3:

dot_product = q_1*k_1 + q_2*k_2 + q_3*k_3

When we square this, we multiply the sum by itself. It is just like expanding (a + b + c)^2:

(a + b + c)^2 = a*a + a*b + a*c
              + b*a + b*b + b*c
              + c*a + c*b + c*c

Here, a = q_1*k_1, b = q_2*k_2, c = q_3*k_3. So we get 9 terms (3 x 3). Now, the key question is: what is the average value of each of these 9 terms?

These 9 terms fall into two groups:

Group 1: Terms where a term is multiplied by itself (like a*a, b*b, c*c)

These are the terms where the same pair is multiplied by itself. For example, (q_1*k_1) * (q_1*k_1) = q_1^2 * k_1^2. There are 3 such terms.

What is the average value of each? Let's use the variance formula we learned above. We know that:

Variance = Average of value^2    (when mean is zero)

Since q_1 has mean 0 and variance 1:

1 = Average of q_1^2
Average of q_1^2 = 1

Similarly, since k_1 has mean 0 and variance 1:

Average of k_1^2 = 1

Since q_1 and k_1 are independent, the average of their product is the product of their averages:

Average of (q_1^2 * k_1^2) = Average of q_1^2 * Average of k_1^2 = 1 * 1 = 1

Each of these terms has an average value of 1.

Group 2: Terms where different pairs are multiplied (like a*b, a*c, b*c)

These are the terms where two different pairs are mixed together. For example, (q_1*k_1) * (q_2*k_2) = q_1 * k_1 * q_2 * k_2. There are 6 such terms.

What is the average value of each? Since q_1, k_1, q_2, k_2 are all independent, the average of their product is the product of their averages:

Average of (q_1 * k_1 * q_2 * k_2) = Average of q_1 * Average of k_1 * Average of q_2 * Average of k_2
                                    = 0 * 0 * 0 * 0
                                    = 0

Here, since each of them has an average (mean) of zero, the entire product becomes zero.

Each of these terms has an average value of 0.

Putting it together:

Out of 9 terms:

3 terms (Group 1) each contribute an average of 1
6 terms (Group 2) each contribute an average of 0

Variance = 3 * 1 + 6 * 0 = 3

And d_k = 3. So the variance equals d_k.

Now, this same logic works for any value of d_k. If d_k = 64, we get 64 * 64 = 4096 total terms. Out of these, 64 terms (Group 1) each contribute 1, and the remaining 4032 terms (Group 2) each contribute 0. So the variance is 64, which is exactly d_k.

The variance of the dot product is always exactly equal to dₖ. This is not an approximation. It is mathematically exact.

What Large Dot Products Do to Softmax

The softmax function converts a list of numbers into probabilities. The formula is:

softmax(x_i) = e^(x_i) / sum(e^(x_j) for all j)

Here, e is the mathematical constant (approximately 2.718).

Now, the important thing to understand is: e^x grows extremely fast as x increases. Let's see with real numbers to understand how fast it grows:

e^1   = 2.718
e^5   = 148.4
e^10  = 22,026
e^20  = 485,165,195
e^50  = 5,184,705,528,587,072,045

Here, we can see that the difference between e^10 and e^50 is astronomically large.

Now, let's say we have three attention scores: [50, 10, 5] (just for the sake of understanding how softmax behaves with large numbers). When we apply softmax:

e^50 = 5,184,705,528,587,072,045
e^10 = 22,026
e^5  = 148

softmax = [5,184,705,528,587,072,045 / total, 22,026 / total, 148 / total]

The first value completely dominates. The softmax output will be approximately [1.0, 0.0, 0.0].

Now, compare this with smaller scores: [5, 1, 0.5]. When we apply softmax:

e^5   = 148.4
e^1   = 2.718
e^0.5 = 1.649

Sum = 152.780

softmax = [148.4/152.780, 2.718/152.780, 1.649/152.780]
        = [0.971, 0.018, 0.011]

Here, we can see that even with smaller scores, the first value still gets the most attention. But the other values are not completely zero. The model can still learn from all positions.

This is the problem. When d_k is large and we do not scale, the dot product scores become so large that softmax outputs become almost one-hot. One-hot means one value is 1.0 and the rest are 0.0. The model acts as if only one word matters and ignores everything else. The gradients vanish, and learning stops.

Why √dₖ is the Right Scaling Factor

Now that we understand the problem, the solution becomes clear. We need to keep the dot product values small enough so that softmax can produce well-distributed attention weights.

We need to bring the variance of the dot product back to 1, regardless of how large d_k is.

We know that:

Variance(dot_product) = d_k

If we divide the dot product by some constant c, the variance becomes:

Variance(dot_product / c) = d_k / c^2

Note: When we divide a random variable by a constant c, the variance gets divided by c^2 (not c). This is a standard rule in statistics. Let's understand why.

Variance measures how spread out values are from the mean. It is calculated using squared differences from the mean. So, when we divide all values by c, each difference from the mean also gets divided by c. But since variance squares those differences, the division by c becomes division by c^2.

Let's see with a simple example. Suppose we have three values: [2, 4, 6].

Mean = (2 + 4 + 6) / 3 = 4

Differences from mean: [2-4, 4-4, 6-4] = [-2, 0, 2]

Squared differences: [4, 0, 4]

Variance = (4 + 0 + 4) / 3 = 2.67

Now, let's divide all values by c = 2. The new values are [1, 2, 3].

New Mean = (1 + 2 + 3) / 3 = 2

Differences from mean: [1-2, 2-2, 3-2] = [-1, 0, 1]

Squared differences: [1, 0, 1]

New Variance = (1 + 0 + 1) / 3 = 0.67

Here, we can see that the original variance was 2.67 and the new variance is 0.67. And 2.67 / 4 = 0.67. We divided by c = 2, but the variance got divided by c^2 = 4.

This happens because variance uses squared differences. When each value shrinks by a factor of c, the squared differences shrink by a factor of c^2.

Now, coming back to our dot product. We had:

Variance(dot_product / c) = d_k / c^2

We want this variance to equal 1 so that the dot product values stay in a manageable range. So, we set:

d_k / c^2 = 1
c^2 = d_k
c = sqrt(d_k)

This is why we divide by sqrt(d_k). It is the exact value that brings the variance back to 1.

After scaling:

Variance(dot_product / sqrt(d_k)) = d_k / d_k = 1

The scaled dot product values now have a variance of 1, meaning they stay in a manageable range regardless of how large d_k is. The softmax function receives reasonable inputs and produces well-distributed attention weights.

This is not an arbitrary choice. It is mathematically the correct scaling factor. The authors of the original "Attention Is All You Need" paper (the paper that introduced the Transformer architecture) chose this value for exactly this reason.

Seeing It with Real Numbers

Now, let's see the effect of scaling with two different dimensions.

Example 1: Small dimension (dₖ = 4)

Let's say we have:

q = [1, 0, 1, 0]
k = [0, 1, 1, 1]

dot_product = 1*0 + 0*1 + 1*1 + 0*1 = 1

sqrt(d_k) = sqrt(4) = 2

scaled_score = 1 / 2 = 0.5

The original score is 1, the scaled score is 0.5. Both values are small, so softmax will behave well in either case. Scaling does not matter much when d_k is small.

Example 2: Large dimension (dₖ = 64)

Let's say we have three words with dot product scores: [14, 10, 12].

Without scaling:

e^14 = 1,202,604
e^10 = 22,026
e^12 = 162,755

Sum = 1,387,386

softmax = [0.867, 0.016, 0.117]

Here, the first word gets 86.7% of the attention. The second word gets only 1.6%. The distribution is quite extreme even though the raw scores (14, 10, 12) are not that far apart.

With scaling (divide by sqrt(64) = 8):

Scaled scores: [14/8, 10/8, 12/8] = [1.75, 1.25, 1.5]

e^1.75 = 5.755
e^1.25 = 3.490
e^1.5  = 4.482

Sum = 13.727

softmax = [5.755/13.727, 3.490/13.727, 4.482/13.727]
        = [0.419, 0.254, 0.326]

Here, we can see the difference. After scaling, the attention is distributed much more evenly: 41.9%, 25.4%, and 32.6%. The model can now learn from all three words instead of focusing almost entirely on one word.

This is how scaling by sqrt(d_k) solves the problem.

Putting It All Together

Let's summarize what we have learned:

The Problem: The dot product of the Query and Key vectors grows in magnitude as the dimension d_k increases. The variance of the dot product is equal to d_k. Large dot product values push softmax into extreme regions where it outputs values close to 0 or 1. This causes the vanishing gradient problem and the model stops learning.

The Solution: We divide the dot product by sqrt(d_k) before applying softmax. This brings the variance back to 1, keeping the scores in a manageable range regardless of the dimension size.

Why sqrt(d_k)? Because when we divide a value with variance d_k by sqrt(d_k), the new variance becomes d_k / d_k = 1. It is mathematically the exact right value.

The full attention formula with scaling:

Attention(Q, K, V) = softmax(Q x K^T / sqrt(d_k)) x V

This single line, / sqrt(d_k), looks simple. But without it, the Transformer architecture would struggle to learn effectively, especially with larger dimensions. It is a small but very important detail that makes the entire attention mechanism work.

Now, we must have understood why we scale the dot product attention by √dₖ.
